• PS8313 / PS8317 UFS

    モバイルデバイスにSSDの性能を備える。

各種のアプリケーションに適用され、

絶好なパフォーマンスと安定な信頼性を備え持つ、大事なデータを保護されることが可能です。

1

2

3

4

Embedded UFS

技術仕様

Controller

PS8313

UFS 2.1

2-ch @ 667 MT/s

Host Interface

M-PHY 3.0, HS-Gear 3B x 2-Lanes

Capacity

up to 256GB (3D TLC NAND Flash)

Sequential Read/Write (up to)

920 / 520 MB/s

Random Read/Write (up to)

67K / 93.5K IOPS

ECC

LDPC

Advanced Features

  • Co-Processor Architecture from PCIe SSDs
  • LDPC and RAID ECC to Support Latest 3D TLC NAND Flash



Controller

PS8317

UFS 3.0

2-ch @ 1,200 MT/s

Host Interface

M-PHY 4.1, HS-Gear 4B x 2-Lanes

Capacity

up to 2TB (3D TLC NAND Flash)

Sequential Read/Write (up to)

1,750 / 810 MB/s

Random Read/Write (up to)

81K / 150K IOPS

ECC

Phison 4th Gen. LDPC

Advanced Features

  • Co-Processor Architecture from PCIe SSDs
  • LDPC and RAID ECC to Support Latest 3D TLC NAND Flash



UFS Card

技術仕様

Controller

PS8313

Interface

M-PHY 3.0, HS-Gear 3B x 1-Lane

Capacity

up to 256GB (3D TLC NAND Flash)

Sequential Read/Write (up to)

515 / 485 MB/s

Random Read/Write (up to)

67K / 93.5K IOPS

ECC

LDPC

Advanced Features

  • Co-Processor Architecture from PCIe SSDs
  • New LDPC to Support Latest 3D TLC NAND Flash

In-House IPs

  • M-PHY 3, HS Gear 3, 2-Lanes
  • UniPro 1.6
  • UFS 2.1
