| Controller | Interface | Capacity | NAND Flash | Sequential R/W | Package Type / Size (mm) | Temperature | Grade |
|---|---|---|---|---|---|---|---|
| PS8229 | eMMC 5.1 | 16GB ~ 32GB | 3D TLC | 280/190 MB/s | 153 Balls (11.5x13x1.0mm) | - 40C ~ 105C | AEC Grade2 |
| PS8229 | eMMC 5.1 | 16GB ~ 32GB | 3D TLC | 280/190 MB/s | 153 Balls (11.5x13x1.0mm) | - 40C ~ 85C | AEC Grade3 |
| PS8231 | eMMC 5.1 | 32GB ~ 256GB | 3D TLC | 320/215 MB/s | 153 Balls (11.5x13x1.0mm) | - 40C ~ 105C | AEC Grade2 |
| PS8231 | eMMC 5.1 | 32GB ~ 256GB | 3D TLC | 320/215 MB/s | 153 Balls (11.5x13x1.0mm) | - 40C ~ 85C | AEC Grade3 |
| PS8225 | eMMC 5.1 | 4GB ~ 16GB | MLC | 225/140 MB/s | 153 Balls (11.5x13x1.0mm) | - 40C ~ 105C | AEC Grade2 |
| PS8225 | eMMC 5.1 | 4GB ~ 16GB | MLC | 225/140 MB/s | 153 Balls (11.5x13x1.0mm) | - 40C ~ 85C | AEC Grade3 |
| PS8225 | eMMC 5.1 | 4GB ~ 16GB | MLC | 225/140 MB/s | 100 Balls (14x18x1.4mm) | - 40C ~ 105C | AEC Grade2 |
| PS8225 | eMMC 5.1 | 4GB ~ 16GB | MLC | 225/140 MB/s | 100 Balls (14x18x1.4mm) | - 25C ~ 85C | AEC Grade3 |
| PS8228 | eMMC 5.1 | 8GB | 2D MLC | 280/105 MB/s | 153 Balls (11.5x13x1.0mm) | - 25°C to 85°C (Tcase) | N/A |
| PS8229 | eMMC 5.1 | 32GB ~ 256GB | 3D TLC | 315/240 MB/s | 153 Balls (11.5x13x1.0mm) | - 25°C to 85°C (Tcase) | N/A |
| PS8231 | eMMC 5.1 | 64GB ~ 512GB | 3D TLC | 320/280 MB/s | 153 Balls (11.5x13x1.0mm) | - 25°C to 85°C (Tcase) | N/A |
| PS8232 | eMMC 5.1 | 32GB ~ 64GB | 3D TLC | 310/180 MB/s | 153 Balls (11.5x13x1.0mm) | - 25°C to 85°C (Tcase) | N/A |
